VLA series elevators are exclusively designed for houses, villas and other private places. It is because of excellent performance, diverse installation solutions, and elevator cars with distinct decoration styles that you will bask in convenience, coziness and nobleness when you take such elevators, and enjoy the ensuing extraordinary perfection in living environment change and living experience.
Top 4 benefits from humanization design:
Environmentally-friendly and energy-saving: the power consumption at 220V or 380V is the same as that for a refrigerator.
Feature: less strict requirements for pit and overhead. No specific machine room needed, more beautiful and comfortable.
Purpose: it is used for villas of various styles and structures.
Style and appearance: it is compatible with various decoration styles.
Dynamic space-breaks fetters of patterns
VLA series elevators occupy the small area of shaft way, has no specific machine room, and apply to various pattern solutions. Due to minimal sizes of their pit and overhead (500mm and 2900mm respectively), the building space and construction costs are substantially saved.
Reliably low speed-provides access to convenience
The travel speed that may be precisely limited to approximately 0.4m/s creates reliability and safety at any time, and provide the elders and children with the coziest riding experience. Besides, for the reason of top-quality components adopted, you will enjoy the uttermost tranquility, without disturbance from noise as mush as possible.
Heavy load-carries more to new high
The load of such elevators is up to 400KG, satisfying the demand to carry more family members and household articles. Thus, more possibilities about living come true.
Permanent magnet synchronous gearless machine
1.VLA series elevators are equipped with Diana IV series rare earth permanent magnet gearless machines, and directly driven by three-phase permanent magnet synchronous electric motors with low speed and high torque. As a result, such elevators have such advantages as low power consumption, less noise, no pollution and less maintenance.
2.The Diana IV series rare earth permanent magnet gearless machine has single winding structure, small size, and compact frame, and in turn,the demand to design villa elevators is satisfied.
3.At 220V working voltage, the incompatibility of power supplies is avoided, together with the realization of low household power consumption and energy conservation.
VLA elevator door machine
1.The adopted specific three-phase asynchronous motor system greatly enhances the open/close sensitivity of elevator doors.
2.The control system adopts integrated machine to run more reliably.
3.The specific interface is used to connect with elevator systems for the more convenient cable connection; besides, the asynchronous door vanes are employed for more safety and reliability.
Smart drive, mission possible
1.VLA series elevators have S50-MCB series control systems integrated with advanced telecommunications technologies such as Canbus, Modbus and GSM. The whole elevator adopts integrated structure, whose travel curve could be adjusted automatically on the basis of distance. Besides, the direct stop technology used for such elevators raises the running efficiency.
2.The fault tolerance design of hardware and software, together with multi safety protection, avoids accidents as many as possible and guarantees the running safety.
3.Under the high-performance vector control, the maximum motor performance is stimulated to generate the best comfortability.
Smart emergency response, people never trapped inside.
Upon the occurrence of breakout or trap, the emergency power supply of the tailored EPS system will be automatically triggered. The smart vocal system will tell the trapped about current information and operation of elevators. Even if the main control system is totally out of service, the emergency devices could still drive elevators to leveling zones for evacuation. If brakes are burnt up, the valve could still be manually operated for evacuation.
Smart intercom device, smooth communications guaranteed
Due to the intercom system embedded in VLA elevators, the emergency call could be forwarded to LDD call or mobile phones via fixed-line telephones after the emergency warning arises, and meanwhile, the real-time talkback is accessible. Besides, such functions as telephone number storage, information inquiry, elevator warning record retrieval, and call forwarding are also embedded to guarantee the safe and reliable communications for the trapped.
